Nail packer for injection hoses

HO-INJECT

Formwork packer for hoses with a 5–7 mm internal diameter. Length 73 mm, passage 2.5 mm. Provides an accessible injection point at the formwork.

Log in to see prices

HO-INJECT SWG

Description

Description

Formwork packer for injection hoses with an inside diameter of 5–7 mm. Nipple type depends on the variant.

Technical information

Material: plastic
Length: 73 mm
Flow bore diameter: 2.5 mm
Nipple thread: M8x1.25

Source: HAMMPACK® 2026 catalogue.

Connecting the 5 mm hose system — 1. Braided injection hose · 2. Plain injection hose · 3. Feed hose 6 × 2.5 mm · 4. Clamp 11–13 mm · 5. HO-CONNECT connector · 6. HO-END filling packer. Maximum active hose length: 10 m per section, according to the catalogue.
