INJECTION PUMP PI-PUMP 6000+

The PI-PUMP 6000+ is a piston pump with simple and proven operation.

• The 2l reservoir is the optimum amount of resin, for those who keep in mind the principle “small amount of mixed resin = always fresh and with lower viscosity, for a better distribution of the grout in the construction”.
• Flow rate control, and working pressure regulator.For better resin distribution in the crack, PI-PUMP 6000+ allows easy and quick adjustment of the injection in several ways:
• You can open the valve and, with short presses of the drill switch, inject the injectant to the selected pressure at the selected flow rate (when you have a pressure of, say, 60 BAR it is all the way from the pressure gauge to the end point of spreading in the crack), gently increasing the pressure with another press of the trigger increases the pressure throughout the injected structure. The pressure control valve on the pump, is then used to set the maximum pressure in the construction.
• We can adjust the speed of the drill to the optimum level so that the flow rate was appropriate for the work carried out (according to the author, slower is better) and set the maximum operating pressure, for example, to 20 Bar and wait for spreading in the crack, then with the pressure regulator on the pump increase the pressure even to 340 BAR!!!  (in most cases 120 – 180 BAR is enough).
• We can adjust any engine speed (flow rate) and any pressure on the pump regulator, open the valve and inject with constant pressure and flow.
  The pump is not designed to pass water through it
